Stanley Super Star

The reconditioned Stanley Super Star from GMH is the most powerful solid fuel heating cooker in our Stanley range and it is also available as a pressure jet model. It has a second warming oven in addition to the main roasting oven and offers contemporary styling with a robust construction.

The solid fuel model has thermostatic airflow control & mechanical riddling along with more traditional features such as an oven-door mounted temperature gauge and under-oven soot door for easy cleaning.

The pressure jet model utilises a single burner for both cooking and heating whereby the hot airflow can be adjusted with a moveable baffle system to divert heat towards either the boiler or the oven.

Both models come with an optional plate rack & splash back panel and you can choose between a solid or glass fronted oven door.

Stanley Super Star Configurations

  • Solid fuel and boilder for up to 12 radiators
  • Oil and boilder for up to 12 radiators

Features

  • Large capacity roasting oven
  • Twin hotplate covers
  • Second warming oven
  • Heats up to 12 radiators
  • Front firebox loading
  • Choice of solid of glass oven door
  • Optional plate rack and splash back


Specifications - Solid Fuel Model

Stanley Super Star
  1. Height 885mm
  2. Width 920mm
  3. Depth 530mm
  4. Depth to bracket 590mm
  5. Flue 6” (125mm) rear centred: H982mm x 130mm from RH edge of hob. Top connection option
  6. Boiler flow pipe 1” BSP rear connection, centred: H595mm x 190mm from LH side panel edge
  7. Boiler return pipe 1” BSP rear connection, centred: H225mm x 190mm from LH side panel edge
  8. Hotplate W560mm x L330mm boiling side
  9. Hotplate simmering side
  10. Roasting oven W390mm x H310mm x D406mm
  11. Simmering oven W390mm x H220mm x D406mm
  12. Fuel: multi-fuel: wood, coal & turf
  13. Thermostatic control of boiler
  14. Firebox dimensions: W430mm x H450mm x D220mm
  15. Height to top of plate rack: 1445mm
  16. Hotplate cover open Max. height 1290mm

Heat Output to Water

  • Total heat output: 35kW
  • Boiler: 17.5kW sufficient for up to 12 radiators

Notes

  • Max. Weight 380Kg
  • Splash back is a cost option


Specifications - Factory Oil 60K Model

Stanley Super Star Oil

Features

  • Height: 915mm
  • Width: 920mm
  • Depth: 530mm
  • Fuel: 28 Sec Kerosene
  • Oil line connection: ¼” BSP Taper on LH side at rear of side panel.
  • Electrical connection: Next to oil line, 240VAC, 50Hz, 5 amp fused
  • Total heat output: 22 kW
  • Maximum radiator area: 32.7M²
  • Sufficient for 12 radiators
  • Heat to room: 2.9kW

Heat Output to Water

  • Total heat output: 22 kW
  • Heat to room: 2.9kW

Click here to view our range of enamel colours or contact us for prices and availability.

We offer a full installation service; however the price may vary depending on any additional preparation work required such as for the chimney or plumbing.

Due to the nature of the casting process all dimensions are subject to slight +/- variations.
